What Is Varnish in Oil?
Varnish in oil is an insoluble film deposit that forms inside turbine lubrication systems and accumulates on surfaces such as bearings, servo valves, heat exchangers, pipes and tanks.
While all turbine oils can generate varnish materials over time, elevated temperatures can accelerate oxidation and increase the rate of deposit formation. Left unmanaged, varnish can reduce equipment reliability, increase maintenance requirements and contribute to costly downtime.
For organisations looking to improve lubrication system reliability, understanding the causes, warning signs and treatment options is the first step towards effective varnish control.
What Problems Does Varnish Cause?
Most varnish within a lubrication system exists as deposits on equipment surfaces, while a smaller portion remains suspended in the oil.
Over time, these deposits can lead to:
- Restriction and sticking of servo valves
- Bearing deposits that reduce oil-film thickness and clearances
- Reduced cooling efficiency in heat exchangers
- Increased maintenance requirements
- Production losses and downtime
Replacing affected components, carrying out chemical cleaning and flushing the system can be costly. Production losses and downtime can add considerably to the overall impact of poor varnish control.
How Can You Identify Varnish in Oil?
Several indicators may suggest varnish contamination is present:
- Dark-coloured oil
- An acidic odour in oil samples
- Non-particulate silt on a 0.8 or 1.2 μm test membrane
- High operating temperatures or hot spots above 80°C
- Servo valve failure
- Last-chance filter clogging in a cold pilot line
- Premature filter plugging
- Sticky residue on system components
If any of these indicators are present, laboratory analysis is recommended.
How Is Varnish Measured?
Measuring varnish potential provides an indication of the varnish precursors present in the oil, but it does not measure the amount of varnish already deposited throughout the system.
A reduction in varnish potential does not necessarily mean a system is varnish-free. Existing deposits must continue to dissolve and be removed before the system can be considered fully cleaned.
Because of this, varnish precursor measurements should remain consistently low over an extended period when evaluating long-term varnish control.
What Are the Most Common Varnish Removal Methods?
Several approaches are used to remove varnish contamination from lubrication systems.
| Method | Approach | Considerations |
|---|---|---|
| Electrostatic removal | Uses an electrical field to encourage varnish particles to agglomerate | Results can vary |
| Chemical flushing | Softens deposits and removes them using circulating flushing fluid | Can be time-intensive and costly |
| Adsorption | Captures varnish precursors using filtration media with high surface area and void volume | Requires a low flow rate to provide sufficient residence time |
Why Does Pall Recommend Adsorption?
The adsorption method uses filtration media with high surface area and void volume. Combined with low flow rates, this allows sufficient residence time for varnish precursors to be captured and removed from the oil.
Pall's VRF (Varnish Removal Filter) system uses an adsorption-based approach to help reduce varnish potential while supporting ongoing system cleanliness. Field experience on gas turbines demonstrated rapid and stable reductions in varnish potential ratings below recommended levels.
When used alongside Pall anti-static filter media on the main lubrication line and an offline CRF skid, the system can help address varnish-related issues and support long-term reliability.
Explore Pall’s Industrial Manufacturing filtration solutions for more information on contamination control.
Proven Performance
Field experience with Pall VRF on gas turbines demonstrated rapid and sustained reductions in varnish potential ratings (VPR) below recommended levels.
As varnish precursors are removed from the oil, existing deposits gradually re-dissolve and are captured through the filtration process. Combined Pall SRT and VRF filtration technologies help organisations remove existing varnish contamination while supporting ongoing varnish prevention.
Learn More About Varnish Prevention and Removal
Varnish contamination can affect reliability, increase maintenance requirements and contribute to unplanned downtime.
To discuss varnish control strategies with a filtration specialist, contact Pall or watch our on-demand webinar:
Frequently Asked Questions
What is varnish in oil?
Varnish is an insoluble deposit formed when oil degradation by-products accumulate on equipment surfaces within lubrication systems.
What causes varnish in turbine oil?
Varnish is commonly associated with oil degradation and oxidation. Elevated operating temperatures can accelerate formation and increase the rate of deposit build-up.
What are the signs of varnish contamination?
Common signs include dark oil, acidic odours, sticky deposits, servo valve sticking, premature filter plugging and elevated operating temperatures.
How is varnish removed from lubrication systems?
Varnish can be addressed through a variety of approaches, including electrostatic removal, chemical flushing and adsorption-based filtration systems designed to remove varnish precursors.
Why is varnish a problem in lubrication systems?
Varnish deposits can restrict servo valves, reduce cooling efficiency, affect bearing performance and increase maintenance requirements, potentially leading to reliability issues and downtime.
